Product Description：

Name：Three box-type Thermal shock Test Chamber

Type：BND-HLR3

Purpose:

It is necessary test equipment for the aerospace, automotive, home appliances, research and other fields, used for examination and identification of parameters, performance and the use of adaptive of electrical, electronics, automotive electronics, materials and other products, after making high and low temperature impact test. Applied to schools, factories, military, research, and other organizations

Product Spec.and Technical parameter table
model						BND-HLR3-80	BND-HLR3-100	BND-HLR3-150
performance	Preheat room		Upper limit preheat temperature			200oC
			Heating time			﹢20～﹢200oC≈20min
	Precool room		Lower limit precool temperature			﹣75oC
			Cooling time			﹢20～﹣70oC≈80min
	Workroom		Temperature shock range			(－55oC～－10)～(50～﹢150oC)
			Temperature fluctuation			≤±0.5oC
			Temperature deviation			≤±2oC
	Temperature revert time					≤5min
	Temperature revert conditions	CJ602S3Ⅰ		Condition 1		sample load: 10kg with plastic package IC；sample exposed: 30min in ﹢125oC,30min in ﹣40oC
				Condition 2		sample load: 10kg with plastic package IC；sampl exposed :30min in ﹢150oC，5min in ambient temp,30min in ﹣55oC
		CJ602S3Ⅱ		Condition 1		sample load: 20kg with plastic package IC；sample exposed: 30min in ﹢125oC,30min in ﹣40oC
				Condition 2		sample load: 20kg with plastic package IC；sampl exposed :30min in ﹢150oC，5min in ambient temp,30min in ﹣55oC
				Condition 3		sample load: 7.5kg with plastic package IC；sample exposed: 30min in ﹢150oC,30min in ﹣55oC
		CJ603S3Ⅰ		Condition 1		sample load: 10kg with plastic package IC；sample exposed: 30min in ﹢125oC,30min in ﹣40oC
				Condition 2		sample load: 10kg with plastic package IC；sampl exposed :30min in ﹢150oC，5min in ambient temp,30min in ﹣55oC
		CJ603S3Ⅱ		Condition 1		sample load: 20kg with plastic package IC；sample exposed: 30min in ﹢125oC,30min in ﹣40oC
				Condition 2		sample load: 20kg with plastic package IC；sampl exposed :30min in ﹢150oC，5min in ambient temp,30min in ﹣55oC
				Condition 3		sample load: 10kg with plastic package IC；sample exposed: 30min in ﹢150oC,30min in ﹣55oC
		CJ605S3Ⅰ		Condition 1		sample load: 10kg with plastic package IC；sample exposed: 30min in ﹢125oC,30min in ﹣40oC
				Condition 2		sample load: 10kg with plastic package IC；sampl exposed :30min in ﹢150oC，5min in ambient temp,30min in ﹣55oC
		CJ605S3Ⅱ		Condition 1		sample load: 20kg with plastic package IC；sample exposed: 30min in ﹢125oC,30min in ﹣40oC
				Condition 2		sample load: 20kg with plastic package IC；sampl exposed :30min in ﹢150oC，5min in ambient temp,30min in ﹣55oC
				Condition 3		sample load: 10kg with plastic package IC；sampl exposed :30min in ﹢150oC,30min in ﹣55oC
construction	shell					cooling steel plate,surface spray
	inner					steel plate
refrigeration	insulate					Rigid Polyurethane Foam+extra-fine glass-wool
	mode					cascade refrigerating compressor
	compressor					import compressor
Cable port(mm)						one on left side Φ50
Controller						color LCD touchscreen display
recording equipment						temperature recorder(optional)
communication Interface						RS485 interface,RS232 interface
Workroom dimensions(mm)					D	400	400	500
					W	500	500	600
					H	400	500	500
Exterior dimensions（mm)					D	2500	2700	2900
					W	1000	1000	1130
					H	1950	2000	2100
Installed power(KW)					Ⅰ	35	48	50
					Ⅱ	46	56	56
Power Supply						AC380V 50Hz Three-phase four-wire + protective earth wire
Standard Configuration						A copy of the instruction and test report for the product, A certificate and quality assurance.2 Shelf and 4 shelves .
Standards Applied						GJB150.5
